SCC AERO - The supercar most powerfull in the world!


MOST POWERFULL THAN THE BUGATTI VEYRON!!!
The Fastest American Cars
Two current American cars could have clobbered the Concorde in a race on the runway.
The storied supersonic jet, which made its final commercial flight in October 2003, had a takeoff speed of 225 mph. For the American SSC Ultimate Aero supercar, which has a top speed of 260 mph to 273 mph, 225 mph sounds like idling speed.
In a recent e-mail message, an SSC spokesman wrote about "loafing around Pocono [a famous NASCAR track in Pennsylvania] at speeds of around 210 mph."




TECHNICAL SPECIFICATIONS
Aero
Ultimate Aero
Engine
Type: Aluminium Block and Heads (V-8)
Displacement: 382 cu.in.
Bore x Stroke: 3.898 x 4.00"
Compression Ratio: 9.2:1
Horsepower: 787 bhp @ 6600 rpm
Torque: 736 lb./ft. @ 5800 rpm
Redline: 7200 rpm
Fuel Injection: Electronic Sequential Port
Weight: 428 lbs
Oil: SAE 5W/30 Fully Synthetic Racing
Induction System: Sequential, multi-port fuel injection. Supercharger with 8 psi boost pressure. Dual-forced air innercoolers.
Fuel: Premium Unleaded - 92 Pump Octane
Engine
Type: Aluminium Block and Heads (V-8)
Displacement: 387.2 cu.in.
Bore x Stroke: 4.125 x 3.620"
Compression Ratio: 8.975:1
Horsepower: 1046 bhp @ 6950 rpm
Torque: 821 lb./ft. @ 6200 rpm
Redline: 7200 rpm
Fuel Injection: Electronic Sequential Port
Weight: 422 lbs
Oil: SAE 5W/30 Fully Synthetic Racing
Induction System: Sequential, multi-port fuel injection. Supercharger with 14 psi boost pressure. Dual-forced air innercoolers.
Fuel: 104 Pump Octane
Warranty
Basic Warranty: 1 Year/Unlimited Miles
Powertrain: 1 Year/Unlimited Miles
Rust-through: N/A
Warranty
Basic Warranty: N/A
Powertrain: N/A
Rust-through: N/A
Chassis and Body
Layout: Mid-Engine/Rear Drive
Body/Frame: Carbon Fiber/Composite/Steel Space Frame
Brakes:
Front: 14.0" Vented Slotted Discs/6-Piston Calliper
Rear: 14.0" Vented Slotted Discs/6-Piston Calliper
Wheels: Forged 3-Piece Alloy
18x9-1/2" Front, 19x13" Rear
Tires: Michelin Pilot Sports
Front: 245 45 18
Rear: 345 30 19
Steering: Rack and Pinion, Assisted
Turns, Lock to Lock: 2.5
Turning Circle: 41.6 ft.
Suspension:
Front: Unequal Length Upper and Lower A-Arms
Coil-Over Springs/Adjustable Tube Shocks
Cab Controlled Air Lift
Anti-Roll Bar
Rear: Unequal Length Upper Rocker and Lower A-Arm
Horizontally Opposed Adjustable Coil-Over Springs
Adjustable Tube Shocks
Anti-Roll Bar
Chassis and Body
Layout: Mid-Engine/Rear Drive
Body/Frame: Carbon Fiber/Composite/Steel Space Frame
Brakes:
Front: 14.0" Vented Slotted Discs/6-Piston Calliper
Rear: 14.0" Vented Slotted Discs/6-Piston Calliper
Wheels: Forged 3-Piece Alloy
19x9" Front, 20x12.5" Rear
Tires: Michelin Pilot Sport PS2
Front: 235 35 (YR)19
Rear: 335 30 (YR)20
Steering: Rack and Pinion, Assisted
Turns, Lock to Lock: 3.5
Turning Circle: 41.6 ft.
Suspension:
Front: Unequal Length Upper and Lower A-Arms
Coil-Over Springs/Adjustable Tube Shocks
Cab Controlled Air Lift
Anti-Roll Bar
Rear: Unequal Length Upper Rocker and Lower A-Arm
Horizontally Opposed Adjustable Coil-Over Springs
Adjustable Tube Shocks
Anti-Roll Bar
The Dynamics of the Aero
Coefficient of drag (Cd): 0.371
Frontal Area: 19.5 square feet
Belly pan: Complete flat belly pan with rear Venturi tunnels.
The Dynamics of the Aero
Coefficient of drag (Cd): 0.357
Frontal Area: 19.0 square feet
Belly pan: Complete flat belly pan with rear Venturi tunnels.
General Data
Dry Weight: 2,850 lbs.
Weight to Horsepower Ratio (lbs/hp): 3.71
Weight distribution F/R:
Front: 42%
Rear: 58%
Wheel Base: 105.2"
Length: 176.2"
Width: 82.7"
Height: 43.0"
Ground Clearance: 4.0"
Trunk Space: 2.6 cu. ft.
General Data
Dry Weight: 2,640 lbs.
Weight to Horsepower Ratio (lbs/hp): 2.52 New production record!
Weight distribution F/R:
Front: 42%
Rear: 58%
Wheel Base: 105.2"
Length: 176.2"
Width: 82.7"
Height: 43.0"
Ground Clearance: 3.5"
Trunk Space: n/a
Accommodations
Seating Capacity: 2
Headroom: 38.5"
Seat Width: 2 x 19"
Leg Room: 47"
Seat Bank Adjustment: 25 Degrees"
Seat Travel: 6.0"
Accommodations
Seating Capacity: 2
Headroom: 38.5"
Seat Width: 2 x 19"
Leg Room: 47"
Seat Bank Adjustment: 25 Degrees"
Seat Travel: 6.0"
Drivetrain
Gear
Ratio
RPM
MPH
1st
3.82:1
7200
44.65
2nd
2.15:1
7200
79.28
3rd
1.56:1
7200
109.27
4th
1.212:1
7200
140.63
5th
0.973:1
7200
175.19
6th
0.656:1
7200
259.75
Final Drive Ratio: 3.44:1
Engine RPM @ 60 Top Gear: 1550
Instrumentation
Gauges:
260-mph Speedometer
8000-rpm Tachometer
Oil Pressure
Water Temperature
Fuel Level
Volt
Audio/Video:
Navigation System
10-Speaker Premium Audio/CD/DVD System
7.5" Video/DVD Screen
Automatic Back-Up Camera
Instrumentation
Gauges:
260-mph Speedometer
8000-rpm Tachometer
Oil Pressure
Water Temperature
Fuel Level
Volt
Audio/Video:
Navigation System (optional)
10-Speaker Premium Audio/CD/DVD System (optional)
7.5" Video/DVD Screen (optional)
Automatic Back-Up Camera (optional)
Standard Equipment
Includes:
Air-Conditioning
Power Windows
Power Mirrors
Tilt-Steering
Cab-Controlled Front Air Lift
Standard Equipment
Includes:
Power Windows
Power Mirrors
Tilt-Steering
Cab-Controlled Front Air Lift
Record-breaking Times
0 to 60 mph: 2.94 seconds
1/4 mile: 10.98 seconds at 138 mph
Skidpad: 1.03 g
0 to 100 mph to 0: 11.66
60 mph to 0 (braking): 103 feet
Record-breaking Times
0 to 60 mph: Not yet established
1/4 mile: Not yet established
Skidpad: 1.03 g
0 to 100 mph to 0: Not yet established
60 mph to 0 (braking): 103 feet
SSC reserves the right to change these specifications without notice.


SSC Ultimate Aero
Base Price: $654,500
Top Speed: 260 to 273 mph
The Ultimate Aero is one of the most extreme vehicles--make that one of the most extreme ideas--of which we have ever heard. It achieves such ridiculous performance with a 1,046-horsepower V-8 engine (you read that hp figure correctly), shoehorned into a car that weighs as much as a Dodge Neon.
